Brother QL-820NWBC desktop USB 2.0 Wi-Fi Ethernet Bluetooth black and red printing label printer
The Brother QL-820NWBC label printer features a built-in wireless and Bluetooth interface which allows you to print from virtually anywhere without being tethered to a computer, with a super-fast print speed of up to 110 standard address labels per minute helps you save time on big projects.
The QL-820NWBC label printer features a built-in wireless and Bluetooth interface which allows you to print from virtually anywhere without being tethered to a computer, with a super-fast print speed of up to 110 standard address labels per minute helps you save time on big projects.
Whether you print one label or multiple labels at a time, the convenient automatic cutter keeps you working efficiently. The QL-820NWB label printer is perfect for labelling packages, envelopes, office supplies, folders and more and prints in red or black.
- Prints in both black and red when used with DK-22251 label roll
- Prints 12mm - 62mm wide labels
- LCD display with backlight
- Plug and play label printer
- 300dpi print resolution
- auto cutter
- up to 60.96mm print width and 1 metre print length
- up to 110 labels per minute printing speed
- USB 2.0, Wireless, Ethernet and Bluetooth interfaces
- free label app for iOS/Android
Printing / Media
| Printing technology | Direct thermal with 2 colour print capability |
| Print resolution | 300x300dpi (standard) / 300x600dpi (high resolution mode) |
| Print speed (single colour)* | Max 176mm/sec (110 labels/minute) |
| Print speed (two-colour)* | Max 24mm/sec (equivalent to 15 labels/minute) |
| Label widths | 12mm -62mm |
| Maximum print width | 60.96mm |
| Maximum print length | 1 metre |
| Media sensor type | Reflective |
| Cutter | Yes (full cut / guillotine type) |
| Media types | DK Rolls (DK die-cut labels / DK continuous tape) |
LCD
| Type | 320x120 dot graphic LCD with backlight |
Connectivity
| USB | USB version 2.0 full-speed (type mini-B connector) |
| USB host capability | Yes (HID class) |
| Bluetooth | Bluetooth 2.1+EDR |
| Bluetooth profiles | SPP(Serial Port Profile) OPP(Object Push Profile) BIP(Basic Imaging Profile) HCRP(Hard Copy Cable Replacement Profile) |
| iOS and Android compatibility | Yes |
| Wireless LAN | IEEE802.11b/g/n |
| Wireless LAN security | WEP, WPA-PSK/WPA2-PSK (TKIP/AES),LEAP (CKIP), EAP-FAST (TKIP/AES), PEAP (TKIP/AES), EAP-TTLS (TKIP/AES),EAP-TLS (TKIP/AES) |
| Airprint | - |
Memory
| Flash (for label templates) | 6MB |
| Locations (for label templates) | 255 |
Power
| Power | 100-240V AC external adapter (auto switching) |
| Battery (optional accessory) | Li-ion battery including base |
| Battery print yield | 4,300 labels (mono) / 1,400 labels (2 colour) |
| Battery Charging time | Less than 2 hours 30 minutes |
Weights/Dimensions
| Dimensions | 125(w) x 234(h) x 145(d) mm |
| Weight | 1.16kg |
Included Items
| In the box | Printer Standard address die-cut labels (100 labels) 2-colour print continuous roll (62mm x 5 metres) USB cable AC power cord Documentation |
* requires DK-22251 roll
| Manufacturer | Brother |
|---|---|
| Print Size | Label |
| Print Method | Thermal |
| Print Resolution | 300x300dpi (standard) / 300x600dpi (high resolution mode) |
| Print Speed | Max 176mm/sec |
| Interface | USB 2.0, Wi-Fi, Ethernet, Bluetooth |
| Label speed | Max 110 labels/minute |
| Barcode Printing | Yes |
| Network Ready | Yes |
| Dimensions | 125(w) x 234(h) x 145(d) mm |
